• Weight 3.82 kg (8.42 lb) (SAR 21)
• Length 805 mm (31.7 in) (SAR 21)

• Barrel length 508 mm (20.0 in)

• Cartridge 5.56x45mm NATO

• Action Gas-operated, rotating bolt

• Rate of fire:450–650 rounds/min

• Muzzle velocity:970 m/s (3,182 ft/s) (M193)
  945 m/s (3,100.4 ft/s) (SS109)

• Effective range:460 m (M193)
  800 m (SS109)

• Feed system 30-round box magazine; plastic or STANAG magazines[1]
  Sights 1.5x or 3x optical sight; back-up iron sights

  next blog post:
  -parts of SAR21
  -Comparisons


  3RD SGT Omar Khalid

• Eject the magazine
• Check Clear
• Put to Safe mode
• Takedown Pin -> Break into Figure "7"
• ...

Assembling a M16S1 Rifle

• ...
• Close the rifle
• Change to semi
• Squeeze trigger
• Insert magazine
• Close Dust Cover

Loading a M16S1 rifle

• Eject the Empty Magazine
• "Empty Magazine check" , Put magazine into pocket
• ...

Unloading a M16S1 rifle

• Eject the Loaded magazine
• "Loaded magazine check"
• ...

Types of IA ( Immediate Action )

• No feeding
• Half-Feeding
• Double-Feeding

• Grip ?
• Breathing techniques ?
• Prone position ?
• Position of rifle butt ?


In order to handle this rifle correctly and effectively, learning every aspect of this weapon is very essential. Therefore, here is some data on the M16S1 rifle.

Characteristics

i) The rifle is light compared to similar weapons used by other Armed forces. It weighs 3.6 kg (8 lbs.) with a fully loaded 30 round box magazine.

ii) The expanding gas, generated when the cartridge is detonated, is used to power the operating parts, which chambers each succeeding round.

iii) The barrel, which becomes hot during firing, is cooled by being exposed to the air. There is no special cooling device.

iv) The ammunition is contained in a metal-box known as a magazine which contains 30 rounds.

v) The rifle is made to fire either single round or multiple rounds when the trigger is held to the rear. When only single rounds are fired, the rifle is said to be operating on the Semi-Automatic mode whilst when more than one round is fired with the squeeze of the trigger, the rifle is said to be operating on the Fully-Automatic mode.

Physical Data

Calibre
5.56mm.

Weight
2.85kg (without magazine)
3.60kg (with 30 rounds magazine)

Length
0.999m.


Effective Range 300m.
Maximum Effective Range 460m.
Maximum Range 2653m.
Muzzle Velocity 990m/sec.
Cyclic 700 to 800 rds per min.

Type of Ammunition Used.

5.56 mm Ball Round
For live firing purposes

5.56 mm Tracer Round
For night live firing purposes

5.56 mm Blank Round
For training purposes

5.56 mm Drill Round
For practice purposes

Don't worry if you cannot remember everything at once. Try to remember as much as you can from the Trainfire course today. I hope you Part A's have learnt much throughout this Trainfire course and certainly the first-hand experience will benefit you in the long run.

Discipline head, 3SGT Nicholas
